9
Additional functions
In set-up mode you can set the child-proof lock and adjust the
brightness of the display*:
Activating set-up mode:
W Press SuperFrost button for approx. 5 secs - the display
shows c for child-proof lock.
Note: the value to be altered flashes.
W Select the required function by pressing the Up/Down button:
c
= child-proof lock or h = brightness.
W Now select/acknowledge function by pressing
SuperFrost button briefly:
• For
c = child-proof lock, press the Up/Down
button to select c1 = child-proof lock on or
c0 = child-proof lock off and acknowledge with
the SuperFrost button. When the symbol 6 is lit,
the child-proof lock is activated.
• For
h = brightness, press Up/Down button to
select h1= minimum to h5 = maximum bright-
ness and acknowledge with the SuperFrost button.
Exit set-up mode:
W To exit the set-up mode, press the On/Off button; after 2 mins.
the electronic system switches over automatically.
- The normal operating mode is activated again.
You are advised to clean the appliance before switching it
on for the first time (see "Cleaning").
Put the appliance into operation approximately 4 hours
before loading with frozen food for the first time. Only insert
frozen food when the freezer compartment is cold.
Switching the appliance on and off Fig. A1
Switching on:
To switch on the entire appliance you only need to switch on
the fridge section.
When the fridge section is switched on, the freezer section
is switched on, too.
- Briefly press the On/Off button 1.
The temperature displays light up. The fridge and freezer
sections are switched on.
Switching off:
- To switch off the entire appliance you only need to switch
off the fridge section. The freezer section is automatically
switched off, too.
- Press the On/Off button 1 for approx. 2s.
- The temperature displays are dark. The appliance is
switched off.
- The interior lighting is dark.
Adjusting the temperature Fig. A1
W Fridge section:
The temperature depends on the following factors:
- The frequency of opening the door
- The room temperature of the installation location
- The type, temperature and quantity of the frozen food
Recommended temperature setting: 5 °C.
The temperature can be changed progressively. When
the setting 2 °C is reached, it begins again at 9 °C.
- Press the temperature setting button 2 repeatedly until
the desired temperature appears in the temperature
display 3.
Note: By pressing the Up/Down button for a long time
activates the nominal value adjustment. The set value blinks
during the adjustment.
- If you press it again briefly, the set value changes in 1°
increments; if you hold it down it will change continuously.
- Approx. 5 seconds after the last button was pressed, the
electronics switch over automatically and the actual
temperature is shown.
W Freezer section:
The recommended temperature setting of 5°C in the cooling
section will produce an average temperature of approx. -18°C
in the freezer section.
Setting up
• The floor on which the appliance stands should be horizontal
and level. To compensate for any unevenness, adjust the
height of the feet with the open-ended wrench supplied.
• Always position the appliance directly up against the wall.
• The ventilation grilles should not be obstructed.
• Condensation may form on the outside of the refrigerator/
freezer during periods of high humidity.
Constant ventilation of the installation site is recommend.
• Do not place heat-emitting appliances, e.g. microwave oven,
toaster, etc., on top of the appliance.
•
In order to avoid the risk of fire, do not place any burning candles,
lamps or other objects with open flames on the refrigerator/freezer.
• Standard EN 378 specifies that the room in which you install
your appliance must have a volume of 1 m
3
per 8g of R 600a
refrigerant used in the appliance, so as to avoid the formation
of inflammable gas/air mixtures in the room where the
appliance is located in the event of a leak in the refrigerant
circuit. The quantity of refrigerant used in your appliance is
indicated on the type plate on the inside of the appliance.
• Fire hazard due to dampness!
If live parts or the mains lead become damp this may cause
short circuits.
- The appliance is designed for use in enclosed areas. Do not
operate the appliance outdoors or in areas where it is exposed
to splash water or damp conditions.
• CAUTION! Risk of injury and danger of damage as a result of
incorrect transport!
- Transport the appliance in a packed condition.
- Transport the appliance upright.
- Do not transport the appliance without assistance.
• The appliance may be moved only when it is empty.
Connecting to the mains
Power supply (AC) and voltage at the operating point must com-
ply with the details on the rating plate. The type plate is located
in the refrigerator compartment on the left-hand side. The socket
must be fused with a 10 A fuse or higher, it must be away from
the rear of the appliance and must be easily accessible.
• Do not connect the appliance to the supply with other equip-
ment using a distribution outlet - risk of overheating.
• Connect the appliance with a properly
earthed fused plug and socket only.
The shelves, Fig. A3, can be adjusted
according to the height of frozen food; to do
this, lift the shelf fowards, pull out half way
and move down (or up).
Always insert trays with stop bar/raised edge
at the back upwards, otherwise food may
freeze onto the rear wall.
Changing shelf arrangement
Remover door racks, Fig. A2
Lift the racks vertically upwards, remove
from the front and reinsert at another height
in the reverse order.
By pushing the bottle holder, Fig.A2,
you can secure bottles against tipping over
when opening and closing the door.The
holder can be removed for cleaning:
- fig.
A2: The holder slides and releases
left or right along the door stops.
Fig. A4. If you need space for large bottles and
containers, then simply push half of glass shelf
1 back. For cleaning the holder 2 can be
used to remove the half glass shelves.
Saving energy
- Always ensure good ventilation. Do not cover ventilation open-
ings or grille.
- Always keep fan louvres clear.
- Do not place appliance in areas of direct sunlight or next to a
stove, heater or similar object.
- The energy consumption depends on the installation condi-
tions, e.g. the ambient temperature.
- Keep the time the appliance is open to a minimum.
- Store food logically.
- Ensure that all food is well packed and covered for storage.
This will prevent frost from forming.
- First cool warm food to room temperature before storing it.
- Defrost frozen food in the refrigerator.
- If there is a thick layer of frost in the ap-
pliance: defrost the appliance.
Accumulated dust increases the energy
consumption:
- Once a year, dust the refrigerating unit
together with the metal grille of the heat
exchanger at the back of the appliance.
* Depending on model and options
