Material supplied

Remove all the components from the packets. Check that all the components are included.

• Hood assembled with motor, lamps and grease filters installed.

• Instructions for assembly and use

• 1 connection ring

• Telescopic flues

• 1 Assembly template

• 6 wall plugs Ø 8mm

• 6 screws Ø 5x45

• 1 cable clamp

• Power cable

• 3 screws Ø 3.5 x 9.5

• 60, 70 and 90 cm wide models only:

1 Flue support bracket

1 baffle

4 screws Ø 2.9x6.5

• 120 cm wide model only:

1 Flue support bracket (3 pieces, for assembly)

1 deflector (3 pieces, for assembly)

4 screws Ø 4x8

8 screws Ø 3.5x9.5

2 screws Ø 2.9x6.5

Installation - preliminary assembly instructions

The hood is designed for installation and use in “Extractor version” or in “Filter version”.

Note: The model with electric shutter can only be used in "Extractor version" and the exhaust pipe must be

connected to a peripheral extraction unit.

Extractor Version

Fumes are extracted and expelled to the outside through an exhaust pipe (not supplied) fixed to the hood

exhaust pipe connector.

Depending on the exhaust pipe purchased, provide for suitable fixing to the exhaust pipe connector.

IMPORTANT: If already installed, remove the carbon filter/s.

Filter Version

Air is filtered through the carbon filter/s and recycled into the surrounding environment.

IMPORTANT: check that air recirculation is facilitated.

If the hood does not have a carbon filter/s, order one/them and fit it/them before use.

Install the hood away from very dirty locations, windows, doors and sources of heat.

The hood comes supplied with all the materials required for installation on most walls/ceilings. However, a

qualified technician is needed to make sure that the plugs are suitable for your ceiling.
