Midea R410A 50Hz T1 Compressor Condensing Unit
10
Model
MCCU-22CN1
Power supply
\
380-415V~, 3Ph, 50Hz
Ambient temperature range
°C
17~52
Cooling
Capacity
kW
22.0
Max. input
kW
11.70
Max. current
A
19.3
Noise level
dB(A)
65
Compressor
Type / Quantity
\
Scroll / 1
Model
\
ZP90KCE-TFD-522
Brand
\
Copeland
Capacity
W
21,900
Input
W
6,950
Capacitor
\
/
Rated current (RLA)
A
16.5
Oil charge
\
2,513 (POE)
Refrigerant
Type / Charged
\
R410A / 5,400g
Fan
Type / Quantity
\
Axial fan / 2
Motor model
\
YDK210-6A
Fan dimension
mm
Φ530
Drive type
\
Direct
Capacitor
\
10μF/450V
Motor input
W
Hi: 284; Lo: 202
Motor speed
rpm
Hi: 920/930; Lo: 650/710 (4 blades/3 blades)
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7.94
No. of rows
\
2
Fin space
mm
1.4
Length × Height
mm
2,177×880
Number of circuits
\
9
Refrigerant
pipe
Liquid side / Gas side
mm
Ф9.52/Ф22
Max. pipe length
m
50
Max. difference in level
m
30
Connection
wire
Power wire
\
5×6.0mm
2
Signal wire
\
2×1.0mm
2
Dimension (W×H×D)
mm
1,260×908×700
Packing (W×H×D)
mm
1,320×1,060×730
Net / Gross weight
kg
171/190
Notes:
Nominal cooling capacities are based on the following conditions:
Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.
