Midea R410A 50Hz T1 Compressor Condensing Unit
12
Model
MCCU-35CN1
Power supply
\
380-400V~, 3Ph, 50Hz
Ambient temperature range
°C
17～52
Cooling
Capacity
kW
35.0
Max. input
kW
17.30
Max. current
A
28.5
Noise level
dB(A)
69
Compressor
Type / Quantity
\
Scroll / 1
Model
\
SH140A4ALC
Brand
\
Danfoss
Capacity
W
34,700
Input
W
10,862
Capacitor
\
/
Rated current (RLA)
A
21.4
Oil charge
\
3,300 (POE-160SZ)
Refrigerant
Type / Charged
\
R410A / 7,200g
Fan
Type / Quantity
\
Axial fan / 2
Motor model
\
YDK400-4C
Fan dimension
mm
Φ530
Drive type
\
Direct
Capacitor
\
25μF/450V
Motor input
W
Hi: 621/587; Lo: 388/388 (4 blades/3 blades)
Motor speed
rpm
Hi: 1,180/1,230; Lo: 790/870 (4 blades/3 blades)
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7
No. of rows
\
3
Fin space
mm
1.3
Length × Height
mm
(1,380×882)+(1,380×882)
Number of circuits
\
20+20
Refrigerant
pipe
Liquid side / Gas side
mm
Ф12.7/Ф28.6
Max. pipe length
m
50
Max. difference in level
m
30
Connection
wire
Power wire
\
5×6.0mm
2
Signal wire
\
2×1.0mm
2
Dimension (W×H×D)
mm
1,260×908×700
Packing (W×H×D)
mm
1,320×1,060×730
Net / Gross weight
kg
199/215
Notes:
Nominal cooling capacities are based on the following conditions:
Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.
