Press the “Enter” button to make the charging current ash. Here you can set the charging
current manually. The upper limit of the available charge current depends on your cell
number and the power capacity of this charger. Refer to the specications section of this
manual for more information.
Finally you have to set the cell balancing function (BLC) to “on” or “o”. Cell balancing
Keep pressing “Enter” until the full-charge-voltage is ashing. The default full-charge-voltage
is 4.20V/cell for Li-Pol batteries and 3.60V/cell for Li-Fe batteries. By pressing “–“ or “+” button,
you can adjust the full-charge-voltage between 3.20V to 4.25V for Li-Pol and 3.00V to 3.80V
for Li-Fe. Attention: We strongly recommend using the default value for Li-Pol/Li-Fe
batteries.
Press the “Enter” button to edit the number of battery cells. Be sure to set the cell count
correctly by using the “+” and “-“ buttons.
Press the “Enter” button to set the capacity. Check your battery’s label or manual to
determine the correct capacity. After you change the capacity value, the charge current next
to it will be changed automatically at 1C.
M01 LP CHG 4.20V 3S
2200mAH 2.2A BLC-ON
M01 LP CHG 4.20V 3S
2200mAH 2.2A BLC-ON
M01 LP CHG 4.20V 3S
2200mAH 2.2A BLC-ON
M01 LP CHG 4.20V 3S
1800mAH 1.8A BLC-ON
M01 LP CHG 4.20V 3S
1800mAH 1.8A BLC-ON
