PRECAUTIONARY MEASURES
ATTENTION:
PLEASE REVIEW THOROUGHLY. NOT FULLY COMPLYING WITH THESE PRECAUTIONS MAY RESULT IN A FIRE HAZARD!!!!!!!
• Do not use the charger inside of a vehicle.
• If using a 12V car battery as in input power source, please completely disconnect the battery from the automobile when using this
charger.
• Never leave this charger to charge batteries unattended.
• Prior to charging make sure that the specications and type of the battery match the settings on the charger.
• Make sure to check that the cell count is correct.
• Never attempt to charge a battery pack if it appears to be damaged.
• Use a high quality power supply for input power source.
• If the battery cell heats up rapidly or expands, cease charging immediately and do not use the battery.
• Do not charge when the ambient temperature is extremely high.
• Do not use an automotive battery charger as a power source.
• Ensure that the charging battery has been connected with the proper (+-) polarity.
• Ensure that the battery has had a chance to cool prior to recharging, as cells may heat up signicantly when discharged at high
current rates.
• Ensure that the charger and battery pack have access to fresh air for cooling.
• Never cover the charger with clothing, pillows or any other loose item while the charger is connected to a power source.
• When charging batteries with this charger, do so in a dry, cool place away from ammable and combustible materials.
• Never store or use the charger in direct sunlight.
• Never expose this charger to any form of moisture. If the charger gets wet, cease from using it to prevent short-circuiting.
• After charging a battery cell, always disconnect the battery from the charger. Never store battery cells when connected to the
charger.
• Never puncture a battery casing.
