FAQ

1. Transmitter and X4 will not bind.

Answer: Throttle position needs to be fully minimized. Please do not move the transmitter sticks or trims

during initial power-on binding.

2. Gyro not working well

Answer: (1) Battery voltage too low. (2) Re-bind (3) Land on to the ground with the throttle fully minimized

for 3 seconds and take o again.

3. Unable to Flip

Answer: (1) Press the Elevator stick one time to enter into the expert(ip) mode. (2) In the expert(ip) mode,

the sensitivity on each channel should be above 90%, you can program the sensitivity in the setup menu.

Please check manual 4.4 Stick Sensitivity Adjustment. (3) Press the throttle stick to turn o anti-ip. (4) Lipo

power is too low and needs to be recharged.

4. Quadcopter is shaking or oscillating with noise.

Answer: Please check to see that the motors, canopy, body and props are all properly positioned.

5. Switching between low and high rates on the transmitter not very user-friendly.

Answer: Press the Elevator stick briey only one time to switch on/o the expert mode(red ashing TX LED)

and normal mode(green solid LED). The word “Expert” will also appear at the bottom center on the LCD.

6. Can not take o.

Answer: (1) Wrong installation of the props. Props are marked with “A”(CW) and “B”(CCW). Please check the

pictures below for the correct order. (2) Wrong installation of motors. Please check to make sure that each

motor is installed in its correct position. There are two dierent types of motors with dierent motor wire

colors. Please check the pictures below for the correct order.

7. One or more motors stop working

Answer: (1) Motor is damaged. Replace the motor. (2) The motor connections(s) are disconnected. Resolder.

(3) An FET on the ight controller looks burned. Replace the ight controller.

(Top View) (Bottom View)

Blue

Red

White

Black
