TRANSMITTER

Input Key Function

Throttle/Rudder Stick

Forward and backward movement of the stick makes the quadcopter ascend and descend respectively. Left and

right movement of the stick will rotate the quadcopter’s fuselage left/right respectively.

Elevator/Aileron Stick

Forward and backward movement of the stick makes the quadcopter move forward and backward respectively.

Left and right movement of the stick makes the quadcopter drift sideways left/right respectively.

Aileron Trim

Aileron trim adjusts for left and right drift.

Identication and functions of the Main Menu

Throttle/Rudder Stick

Power SW

Antenna

Elevator Trim

Aileron Trim

Elevator/Aileron stick

PACKAGE CONTENTS

• 100% assembled R/C Quadrocopter Pilotage Nano-X – 1 pcs

• Transmitter (TX) – 1pcs

• Li-Pol Battery 1S 3.7V, 100mAh – 1 pcs

• USB Cable for Charging – 1 pcs

• Main Rotor Set A&B – 4 pcs

• Instruction manual– 1 pcs

Required for Operation (sold separately):

• 2 pcs AAA battery
