Technical data

13 TECHNICAL DATA

Chain saw CS 4235

Item no. 113616

Idling speed 15 – 20m/s

Operating speed 7 – 20m/s

Chain sprocket pitch 3/8”

Chain brake Yes (electrical, PCB and

brake rod)

Chain run-on time (DIN EN 60745-2-13 – 19.107) Max. 0.15s

Chain run-on time (DIN EN 50144-2-13:2001 – 18.104) Max. 2s

Activation of the chain Twofold

Chain oil tank volume 250ml

Weight with guide rail and saw chain 3.80kg

Weight without guide rail and saw chain 3.15kg

Overload protection No

Sound power level LwA (DIN EN ISO 3744) 108dB(A)

Sound pressure level LpA 88dB(A)

K = 3.0dB(A)

Vibration value (DIN EN 28662-1)* 2.5m/s

K = 1.5m/s

Saw chain 90PX040X 91PX045X 91PX052X

Drive link thickness 1.1mm 1.27mm 1.27mm

Chain bar 104MLEA041 120SDEA041 140SDEA041

Length of the guide rail 10" / 25cm 12" / 30cm 14" / 35cm

Cutting length 17cm 22cm 27cm

* Notes:

■

The vibration emission value given has been measured according to a standardised test method

and can be used to compare one power tool with another.

■

The vibration emission value can also be used for an initial assessment of the exposure (vibration

exposure degree).

■

The vibration emission value may differ from the given value during actual use of the power tool,

depending on how the power tool is used.

■

Try to keep the vibration load as low as possible. Exemplary measures to reduce vibration are the

wearing of gloves when using the tool and the limitation of working time. All parts of the operating

cycle must be taken into account (e.g. times when the power tool is switched off and those in which

it is switched on but runs without load).
