Husqvarna 420EL [27/28] Technical data

English – 27

TECHNICAL DATA

Guide bar and saw chain combinations

The following cutting attachments are approved for the models Husqvarna 418 EL and 420 EL..

Saw chain ﬁling and ﬁle gauges

EC Declaration of Conformity

(Applies to Europe only)

Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel:+46-36-146500, declares under sole responsibility that the corded

electric chainsaws 418 EL and 420 EL from 2016’s serial numbers and onwards (the year is clearly stated in plain text

on the type plate with subsequent serial number), are in conformity with the requirements of the COUNCIL’S

DIRECTIVES:

- of May 17, 2006 ”relating to machinery” 2006/42/EC.

- of February 26, 2014 ”relating to electromagnetic compatibility” 2014/30/EU.

- of May 8, 2000 ”relating to the noise emissions in the environment” 2000/14/EC.

The following standards have been applied: EN 60745-1:2009 + A11:2010, EN 60745-2-13:2009 + A1:2010, EN 55014-

1:2006 + A1:2009 + A2:2011, EN 55014-2:2015, EN 61000-3-2:2014, EN 61000-3-3:2013

Notiﬁed body:

NB2140, DEKRA Testing and Certiﬁcation Gmbh, Enderstraße 92b, 01277 Dresden, Germany, has carried out EC

type examination in accordance with the machinery directive’s (2006/42/EC) article 12, point 3b. The certiﬁcates for EC

type examination in accordance with annex IX, have the numbers: 4815039.16001-1

For information relating to noise emissions, see the Technical data chapter.

The supplied chain saw conforms to the example that underwent EC type examination.

Huskvarna September 1, 2016

Lars Roos, Development manager

(Authorized representative for Husqvarna AB and responsible for technical documentation.)

Model

Guide bar Saw chain

Length, cm/

inch

Pitch, inch Gauge, mm

Max. nose

radius

Type

Length, drive

links (no.)

418 EL 14 (35)

3/8 1,3 7T Husqvarna H37

420 EL 16 (40) 56

inch/mm inch/mm

5/32 / 4,0 80

0.025 / 0,65

5796536-01
