0478 201 9811 B - EN
16
9.1 Motor restart inhibitor
The machine can only be started via the
switch and not by plugging the electric
cable into the mains socket.
9.2 Shredder box
The garden shredder can only be switched
on with the shredder box installed and
locked in place.
Once inserted, the shredder box prevents
access to the rotating blade roller during
operation.
10.1 Electrical connection of garden
shredders
Power supply and operating voltage must
correspond (see identification plate).
The power cable must be adequately
protected by fuse. (Ö 15.)
Only electric cables which are no lighter
than rubber sheathed cables
H07 RN-F DIN/VDE 0282 may be used.
The plug connections must be splash
proof. Unsuitable extension cables lead to
a loss of power and may result in damage
to the motor.
The minimum cross-section of the power
cable must be 3x1.5mm² for a length of
up to 25 m or 3x2.5mm² for a length of
up to 50 m.
The connectors of the electric cable must
be made of rubber or have a rubber
coating and conform to the DIN/VDE 0620
standard.
This machine is intended for operation with
a power supply having a system
impedance of Z
max
at the transfer point
(house connection) of maximum
0.49 Ohm (at 50 Hz).
The user must ensure that the machine is
only operated with a power supply which
meets this requirement. If necessary, this
information can be obtained from the local
electric power company.
10.2 Connecting the power cable
● Connect the mains cable
connector to mains plug (1).
● Attach the mains cable to the strain
relief. (Ö 10.4)
10.3 Disconnecting the power cable
● Detach the strain relief. (Ö 10.4)
In order to prevent damage to the power
cable, it must only be disconnected by
pulling at the connector. Never pull at the
cable.
10.4 Strain relief
During work, the strain relief
prevents any unintentional
disconnection of the electric cable and any
resulting damage to the mains connection
on the machine.
For this reason, the electric cable must be
fed through the strain relief.
● Connect the power cable. (Ö 10.2)
● Form a loop in electric cable (1) and
guide it through opening (2).
● Then push the loop over hook (3) and
pull it tight.
10.5 Inserting the shredder box
● Insert shredder box (1) at the two
guides (2) and push in as far as it
will go.
● Turn locking knob (3) to the right as far
as it will go and secure the shredder
box.
10.6 Removing the shredder box
● Switch off the machine. (Ö 10.8)
● Turn locking knob (1) to the left
as far as it will go.
● Pull out shredder box (2).
9. Safety devices
10. Operating the machine
Risk of injury!
Observe the instructions in section
"Warning – dangers caused by
electrical current" (Ö 4.2).
Your electrician can provide further
information on mains connection.
6
The garden shredder can only be
switched on with the shredder box
locked in place.
The garden shredder cannot be
operated without the shredder box.
7
8
9
