– 6
The scope of delivery of the device (depending on the
model) is illustrated on the packaging. These operating
instructions describe all possible options.
See fold-out page 4 for illustrations
1 Coupling element for water connection
2 Water connection with integrated sieve
3 High pressure hose
4 Hose guide
5 Storage for spray lance
6 Storage / parking position for trigger gun
7 Connection for Plug 'n' Clean detergent
8 Carrying handle
9 Transport handle, detachable
10 High-pressure hose drum
11 Hand crank for hose drum
12 Appliance switch „0/OFF“ / „I/ON“
13 Mains cable with mains plug
14 Accessory compartment
15 Hooks for fastening the net
16 Net for accessory compartment
17 Bearing wheel
18 Base with carrying handle
19 Full Control trigger gun
20 Battery compartment
21 Battery compartment lock
22 LCD display
23 Battery status (empty, almost empty, medium, full)
24 Signal strength status (four levels)
25 Spray type recommendation (flat stream/detergent/
dirt grinder)
26 Area of application (1 - SOFT / 2 - MEDIUM / 3 -
HARD with two pressure levels each)
27 Detergent level (1 / 2 / 3)
28 Pressure regulation + / -
29 Lock trigger gun
30 Button for detaching the high-pressure hose from
the trigger gun
31 3-in-1 multi jet spray lance (with three spray types)
32 Detergent nozzle (three dosing levels) - For dosing
detergents
33 Flat jet nozzle (three areas of application with two
pressure levels each) - for the most common clean-
ing tasks.
34 Dirt grinder (one area of application with two pres-
sure levels) - for stubborn contamination.
See fold-out page 3 for illustrations
Mount loose parts delivered with appliance prior to start-
up.
You will need the 2 included screws as well as a Philips
screwdriver PH 2.
Illustration
Insert base.
Insert the included dowels all the way into the
holes.
Secure the base with the enclosed screws.
Illustration
Hook in storage for spray lance.
Secure the storage for the spray lance by means of
two screws.
Illustration
Attach the transport handle.
Secure the transport handle by means of two
screws.
Illustration
Hook the net into the hooks shown in the illustra-
tion.
Before initial startup, the high-pressure
gun must be coupled to the high-pressure
cleaner.
Insert the mains plug into the socket.
Immediately thereafter, simultaneously
press the + and - buttons on the high-
pressure gun.
Hold down the buttons until the entire
signal strength symbol flashes.
Once coupling is complete, all six pressure levels
will be displayed.
Park the appliance on an even surface.
Illustration
Put the high-pressure hose through the hose guide
from the back.
Illustration
Push the high pressure hose into the trigger gun
until it locks audibly.
Note: Make sure the connection nipple is aligned
correctly.
Check the secure connection by pulling on the high
pressure hose.
Unwind the high pressure hose from the hose
drum.
Insert the mains plug into the socket.
Description of the Appliance
* Optional
35 Plug 'n' Clean detergent bottle with locking lid
** Additionally required
36 Fabric-reinforced water hose with commercially
available coupling.
– Minimum diameter, 1/2 inches (13 mm).
– Minimum length 7.5 m.
Assembly
Installing the base
Install storage for spray lance
Install the transport handle
Attach the net to the accessory compartment
Coupling of the high-pressure gun
Start up
