3
ENGLISH
(Original instructions)
u Move the lever towards the rear of the appliance to lower
the height of cut.
u Move the lever towards the front of the appliance to raise
the height of cut.
u Push the height adjustment lever (7) into one of the 6
height locations.
Note: The height of cut can be viewed on the height of cut
gauge (8) on the side of the unit.
Switching on and off (g. I)
Switching on
u Push in and hold the lock-off button (27).
u Pull the on/off switch (2) towards the handle.
u Release the lock-off button.
Switching off
u Release the on/off switch (2).
Warning: Never attempt to lock a switch in the on position.
Mowing (g. P1 & P2) (EMax38i & EMax42i only)
We recommend to use your mower as outlined in this section
in order to achieve optimum results and to reduce the risk of
cutting the mains cable.
u Loop the mains cable through the intelligent cable
management system (4) as shown (g. H) ensue that you
leave approximately 100 cm of cable between the switch-
box (1) and the intelligent cable management restraint (4).
u Ensure that the cable restraint can slide freely from one
handle to the other.
u Place the bulk of the mains cable on the lawn, close to the
starting point (position 1 in g. P1).
u Switch the appliance on as described above.
u Proceed as shown in g. P1
u Move from position 1 to position 2.
u Turn right, stepping over the cable and proceed towards
position 3. The cable restraint will slide from one side of
the handle to the other ensuring that the cable is laid out
away from the cutting blade.
u Turn left, stepping over the cable and move towards posi-
tion 4. The cable restraint will slide from one side of the
handle to the other ensuring that the cable is laid out away
from the cutting blade.
u Repeat the above procedure as required.
Warning: Do not work towards the cable as shown in g. P2.
Mowing (g. P1 & P2) (EMax34s & EMax34i only)
We recommend to use your mower as outlined in this section
in order to achieve optimum results and to reduce the risk of
cutting the mains cable.
u Place the bulk of the mains cable on the lawn, close to the
starting point (position 1 in g. P1).
u Switch the appliance on as described above.
u Proceed as shown in g. P1
u Move from position 1 to position 2.
u Turn right and proceed towards position 3.
u Turn left and move towards position 4.
u Repeat the above procedure as required.
Warning: Do not work towards the cable as shown in g. P2.
EdgeMax (g. K1 & K2)
EdgeMax allows you to cut grass right up to the edge of a wall
or fence (g K1).
EdgeMax allows you to accurately cut grass right up to the
edge of your lawn (g K2).
u With the lawnmower parallel with the edge of your lawn.
u Push the lawnmower along the edge of the lawn. Ensure
that the EdgeMax (9) is slightly over the edge of your lawn
(g.K2)
Note: The roller underneath the appliance provides stability
when mowing over the edge of your lawn.
Compact&Go (g. J) (EMax34i, EMax38i & EMax42i
only)
When the grass collection box is full you can compact the
grass in the collection box. You can determine how full the
grass collection box is by looking through the clear grass ap
(11).
u Release the on/off switch (2).
u Using your right foot, press the grass compaction lever
(29) all the way down until it locks into place.
Note: The grass in the collection box is now compressed into
the rear of the box. You may continue mowing until the grass
collection box becomes full.
Emptying the grass collection box (g. J) (EMax34i,
EMax38i & EMax42i only)
u Release the on/off switch (2).
u Remove the grass collection box (10).
u Empty the contents from the front of the box.
u Place the grass collection box on the ground and pull in
and hold the grass compaction lever release button (30).
u Lift the grass compaction lever (29) into the vertical
position and release the grass compaction lever release
button (30).
u Empty the contents from the rear of the box.
Emptying the grass collection box (EMax34s only)
When the grass collection box is full you should empty the
grass in the collection box.
u Release the on/off switch (2).
u Remove the grass collection box (10).
u Empty the contents from the box.
