4
ENGLISH
(Original instructions)
Cable storage (g. O)
The cable holders (6) provide a safe and convenient way to
store the cable (31) when not in use.
u Wrap the cable around the cable holders (6) in a gure of
eight pattern.
Carrying the mower
Warning! Ensure the blade has completely stopped and
disconnect the appliance from the mains.
u The mower can be carried using the convenient carry
handles (12).
Hints for optimum use
u If the grass is longer than approximately 10 cm, make two
cuts to obtain a better nish. First mow at maximum height
of cut, then use a low or medium height of cut.
u In order to achieve optimum results, only mow dry grass.
Troubleshooting
If your appliance seems not to operate properly, follow the
instructions below. If this does not solve the problem, please
contact your local Black & Decker repair agent.
Warning! Before proceeding, remove the plug from the
socket.
Problem Possible Cause Possible solution
Machine fails to
operate
Power turned off Turn power on
Fuse faulty/blown Replace fuse
Grass too long
Increase the height of
cut and move machine
to shorter grass to start
Thermal cut out
activated
Allow motor to cool and
increase height of cut
Machine functions
intermittently
Thermal cut out
activated
Allow motor to cool and
increase height of cut
Machine leaves
ragged nish or
motor labours
Height of cut too low Increase height of cut
Cutting blade blunt Replace the blade
Underside of machine
clogged
Check underneath the
machine and clear out
as necessary (always
wear heavy duty
gloves)
Blade tted upside
down
Ret blade correctly
Technical data
EMax34s
EMax34i
Type 1
EMax38i
Type 1
EMax42i
Type 1
Voltage
V
AC
230 230 230
Power Input
W
1400 1600 1800
No-Load Speed
min
-1
3500 3500 3500
Height adjustment
mm
200-700 200-700 200-700
Blade length
mm
340 380 420
Weight
kg
11 12 12.6
Hand/arm weighted vibration value according to EN 60335:
= 3.2 m/s
2
, uncertainty (K) = 1.5 m/s
2
.
