Al-Ko T 15-92.6 HD A [30/78] Seite 1
![Al-Ko T 15-92.6 HD A [30/78] Seite 1](/views2/2001134/page30/bg1e.png)
GB 16
GB
Setting the cutting height
The blades are raised and lowered with the position lever
to the right of the driver's seat.
Six height settings with a cutting height between 30 and 90
mm are possible.
Allow the position lever to engage at the height adjustment
position required.
Adjustment of the cutting height can be done both at a
standstill and also during movement.
Attention:
Set the highest cutting height:
- before switching the cutting appliance on
- when driving without mowing
Driving without traction (pushing)
Attention!
Only with the engine switched off and the blades stationary!
Driving and mowing
In order to achieve a tidy mowing result, the traction speed must
be adapted to the state of the lawn.
a) Lever position for hydrostat drive:
- long / thick grass and wet grass: 0 - ¼
- normal grass, weekly cutting: ½ - 2/3
The lever positions from 2/3 - 1/1 are reserved for driving
without mowing.
39
40
37
Driving with the lawn tractor
• Push the right-hand pedal (clutch/brake) right down
- possibly engage with the stop lever.
The mowing appliance must not be switched on.
• Start the engine.
with hydrost
at-drive / with hand switching lever:
• When the engine is running release the brake - (remove your foot
from clutch/brake pedal).
• Select forward or reverse drive with the hand switching lever.
For the first use of the lawn tractor, we would advise you to only
drive at minimum speed.
with hydrost
at-drive / with foot pedal:
• When the engine is running release the brake - (remove your foot
from clutch/brake pedal).
• Select forward or reverse drive with the appropriate foot pedal.
For the first use of the lawn tractor, we would advise you to only
drive at minimum speed.
Brakes
• Press the right-hand pedal
down completely in order to brake.
Switching the mowing appliance on
• Only switch the mowing appliance on with the engine running.
• Put the gas lever into the position.
• Put the mowing appliance switch onto position "I".
• Set the required cutting height.
Attention!
Before switching the mowing blade on, allow the engine to warm
up for about 1 minute!
When you switch the mowing appliance on, the mower should not
be standing in long grass. Set to the highest cutting height.
a) For a hydrostat drive with hand switching lever:
1. Remove or lift up the grass box.
2. Pull out bypass lever and engage downwards .
3. Release the brake.
The lawn tractor can now be pushed without any difficulty.
b) For a hydrostat drive with foot pedal:
1. Remove or lift up the grass box.
2. Push in the bypass lever an engage (downwards).
The lawn tractor can now be pushed without any difficulty.
40a
Switching the mowing appliance off
• Put the mowing appliance switch onto position "0".
• The mowing appliance can be switched off both at a standstill and
also during movement.
Attention!
A rotating / slowing blade can cut hands and feet.
Therefore, keep your hands and feet away from the blades.
1
2
In a normal case, the cutting height is about 4-5 cm. This corresponds
to the 2nd/3rd position of the height adjustment. Cut moist or wet grass
with a higher cutting height.
The best thing to do with very long grass is to cut it twice. For the first
cut, set the machine to max. cutting height and set it to the required
height for the second cut.
