Shorten or remove the tractor drawbar so it will not interfere with the up and down movement of the

mower.

Do not get between tractor and mower when the engine is running.

ATTACHING THE MOWER TO TRACTOR (LIFT TYPE ONLY)

This mower is designed for tractors with 540 RPM and category I hitch. Back the tractor up to the

mower so that the lower draft arms are in alignment with the mower lift pins. Stop the engine, lock the

brakes or place the tractor in park. Connect the tractor and stabilizer bars to the lower lift pins. Adjust

the top link so it will pin to the top holes in the A-Frame or into the holes in the floating top link.

Never allow children to operate, ride or come close to the mower or tractor. Usually, 15-16

year old children who are mature and responsible can operate the mower with reasonable

safety if they have read the operator's manual, been trained in safe operation of the machine,

and are physically large and strong enough to reach and operate the controls easily.

DRIVELINE ATTACHMENT TO TRACTOR

1. Slide yoke onto the tractor PTO shaft.

2. Move yoke back and forth until locking pin has engaged on the PTO shaft groove.

When attaching the driveline yoke to the tractor PTO shaft, it is important that the spring

activated locking pin seats properly in the tractor PTO shaft groove.

CUTTING HEIGHT ADJUSTMENT

Avoid personal injury! Be sure tractor engine is off, that key is removed from ignition and

allow blades to completely stop turning before dismounting to make adjustments.

Important: Avoid very low cutting heights. Striking the ground with the blades gives the most

damaging shock loads a mower can encounter and will cause damage to it and the driveline.

1. Using the tractor, raise the mower off the ground and place supports underneath of it, so that it will

not drift downwards while making adjustments or maintenance.

2. While supporting the wheel and yoke assembly off the ground, remove the snapper pin from the

top of the gauge wheel spindle. Position the supplied spacers as required for achieving the desired

cutting height.

TRACTOR REQUIREMENTS AND PREPARATION

This Finishing Mower is designed for light duty cutting such as lawn maintenance with a Category I,

3 pt. hitch and with a 540 rpm PTO. This mower is not designed for tractors over 40 horsepower. The

PTO must be in good working condition.

It is recommended that only tractors with wide front axles be used with this cutter. Tricycle front

wheel arrangements are inherently unstable and tractor rollover accidents are more likely to occur.

Tractor wheel tread spacing should be increased when working on inclines or rough ground to

reduce the possibility of tipping.

The tractor also needs lift arm stabilizer bars or sway blocks to control side movement of the cutter.

Check the tractor's 3 pt. hydraulic lift system. Refer to your tractor operator's manual or dealer for

any adjustments necessary to put the hydraulic system in good working order.

Be sure tires and rims are in good condition. Inflate tires to the proper recommended air pressure.
