Step 4: Install rear discharge chute and safety chains using M12 bolts and locking nuts. See figure

below:

Step 5: Adjust the height of the mower deck by installing spacers (A, B, or C) on the bottom of the

wheel assembly shaft (2) before inserting into axle arm (3). See figure below:

OPERATION INSTRUCTION

The safe operation of this mower is the responsibility of the operator. The operator should be

familiar with the machine, tractor and all safety practices before starting operation. This mower is

designed for lawn and grass mowing. It is not designed for rough conditions or heavy mowing. The

mower is equipped with suction type blades, which are best suited for lawn mowing.

Always operate tractor PTO at 540RPM.

This chapter provides information for attaching mower to tractor and preparing it for field operation.

Review this data prior to tractor hookup and operation.

TRACTOR PREPARATION

Do not install mower on a tractor over 40 HP

Do not operate tractor with less than 20% of its gross unballasted mass on the front wheels

with the mower in the transport position.

WHEEL TREADS

Tractor wheel tread spacing should be increased when working on inclines or rough ground to

reduce the possibility of tipping.

STABILIZER BARS AND SWAY BLOCKS

Use stabilizer bars or sway blocks to prevent side sway of the mower.

DRAWBAR
