TROUBLESHOOTING (Continued)

3. Stop and wait until is dried

Gearbox overheating

1. Low on lubricant

2. Improper type lubricant

3. Excessive trash build-up around

gearbox

1. Fill to proper level

2. Replace with proper lubricant

3. Remove trash

Gearbox leaking

1. Damaged oil seal

2. Bent shaft

3. Shaft rough in oil seal area

4. Oil seal installed wrong

5. Oil seal not sealing in the

housing

6. Oil level too high

7. Hole in gearbox

8. Gasket damaged

9. Bolts loose

1. Replace seal

2. Replace oil seal and shaft

3. Replace or repair shaft

4. Replace seal

5. Replace seal or use a sealant on

outside diameter of seal

6. Drain oil to proper level

7. Replace gearbox

8. Replace gasket

9. Tighten bolts

NOTE: Since the oil heats, the gearbox may reach a rather high temperature during work and its out

surface may become "hot" to touch. This is normal and will cause no damage. It is, however, important

to always check that the oil is at the correct level and of the indicated type.

PTO contacts mower

front frame when raised

Raising mower too high or incorrect

adjustment of tractor top link

Adjust top link or tractor lift stops (See

attachments instructions)

Gearbox noisy

1. Worn bearings

2. Low oil in gearbox

1. Replace bearings

2. Check level and add oil

Blades wear too fast

1. Cutting in sandy conditions

2. Cutting in rocky conditions

3. Blades hitting ground

1. Increase cutting height

2. Increase cutting height. Remove

rocks

3. Increase cutting height

PROBLEM

POSSIBLE CAUSE

SOLUTION

Mower seems to require

excessive power

1. Advancing into grass too rapidly

2. Hitting ground

3. Worn or dull blades

4. Tractor not large enough

5. Grass wet

6. Grass too tall and heavy

1. Reduce forward travel speed

2. Raise mower and reset wheels

3. Sharpen or replace blades

4. Use larger horsepower tractor

5. Allow grass to dry before mowing

6. Slow ground speed of tractor but

keep engine running at full PTO rpm.

Make two passes. Raise mower for first

pass and lower for next pass.

Mower moves from side

to side when cutting

Loose tractor sway chains or bars,

or sway blocks improperly installed

Adjust sway chains, bars, or sway

blocks
