ECHO INCORPORATED ECHO PPT-235ES (деталировка) [31/42] Ppt 235es power pruner control handle
![ECHO INCORPORATED ECHO PPT-235ES (деталировка) [31/42] Ppt 235es power pruner control handle](/views2/2002323/page31/bg1f.png)
REMARKSDESCRIPTIONQTYPART NUMBERITEM
NUT1900502000061
FLANGE NUT1900515000062
SCREW 5X187V2530002103
HANDLE - RIGHT1C0410000004
SCREW 5X202V2530002205
CLAMP2V4950006806
HANDLE - LEFT1C0410000117
LOCKOUT, TRIGGER1C4600001008
SPRING, TRIGGER LOCKOUT1V4520003409
TRIGGER1C45000026010
SPRING, TRIGGER1V45200033011
INCLUDES ITEMS 13-14CONTROL CABLE ASY1P02103376012
SCREW 3X101915450301013
KNOB, SWITCH1A44400002014
INCLUDES ITEMS 16-17PIPE ASY1C05000077015
WASHER2V58300011016
LINER1C50700016017
COVER - CORRUGATED1V47500400018
DRIVESHAFT - FLEXIBLE1C50600014019
