REMARKSDESCRIPTIONQTYPART NUMBERITEM
COVER, ENGINE1A1600010901
SCREW 5X161V8050001502
SCREW 5X16 - TAPPING1V8050000003
SCREW 5X201V8050001604
WASHER1900603000055
SCREW 5X16 - TAPPING1V8050000006
SCREW 4X164V8040000607
INCLUDES ITEMS 9-16RECOIL STARTER ASY1A0510013118
SCREW1177236618309
PLATE, CAM1P02200828010
SPRING, DAMPER1P02200827011
ROPE, STARTER - 3X700mm1P02201999012
STOPPER, ROPE11772461112013
GRIP, STARTER11772282703014
DRUM1P02200683015
SPRING, REWIND1P02201968016
INCLUDES ITEMS 18-20STARTER PAWL ASY1A05200018017
E-RING2P02200210018
SPRING, RETURN21772341222019
PAWL, STARTER2P02200685020
99922200670 - 5 - REVISED 10/20/09
