ECHO INCORPORATED ECHO PPT-235ES (деталировка) [9/42] Ppt 235es power pruner intake
![ECHO INCORPORATED ECHO PPT-235ES (деталировка) [9/42] Ppt 235es power pruner intake](/views2/2002323/page9/bg9.png)
REMARKSDESCRIPTIONQTYPART NUMBERITEM
THUMB SCREW1V2990002501
LID, AIR CLEANER1A2320004802
FILTER, AIR1130310541303
SCREW 5X652V8050001004
NUT2900500000055
PLATE, PREVENT1129011527306
CASE, AIR CLEANER1P0210128707
See Carburetor Diagram For Additional InformationCARBURETOR1------------------8
GASKET, INTAKE
1
1V1030004809
SCREW 5X202V80500016010
INSULATOR, INTAKE11300174433111
SHIELD, INTAKE
1
1V10300049012
Footnotes
1: Also Included In GASKET KIT
99922200670 - 9 - REVISED 10/20/09
