Husqvarna T435 (2009) parts [17/27] Page h t435

Page H T435 HANDLE COMP

Position Part nr. Quantity Description Kit

1 522 01 64-01 1 Housing

2 522 01 77-01 1 Filter cover compl.

3 522 01 78-01 1 Filter cover 2

4 522 01 79-01 1 Knob 2

5 522 64 76-01 1 Fuel hose assy

6 522 64 77-01 1 Grommet 5

7 522 63 95-01 1 Fuel hose 5

8 516 97 28-01 1 Purge

9 516 94 81-01 1 Seal

10 516 96 19-01 1 Valve

11 522 01 76-01 1 Bracket

12 516 96 52-01 1 Breather

13 520 99 61-01 1 Grommet

14 522 00 88-01 1 Guide, carb

16 523 07 14-01 1 Decal, warning

17 522 01 94-01 1 Eyelet

18 522 01 82-01 2 Fuel cap compl.

19 522 01 83-01 2 Fuel cap 18

20 522 01 84-01 2 Seal 18

21 521 51 80-01 1 Screw

22 522 64 71-01 1 Pipe

23 522 64 78-01 1 Hose connector

24 516 95 03-01 1 Joint

25 522 63 94-01 1 Hose

26 522 63 53-01 1 Decal, warning US-CAN

27 522 63 54-01 1 Decal, warning EU-ROW

28 503 44 32-01 1 Fuel ﬁlter 5

29 522 01 93-01 1 Plate
