Husqvarna T435 (2009) parts [25/27] Page m t435

Page M T435 CARBURETOR

Position Part nr. Quantity Description

Kit

1 522 00 76-01 1 Carburettor

2 521 57 56-01 1 Cover 1

3 521 06 63-01 1 Spring, Idle 1

4 516 77 83-01 1 Screw 1

5 520 95 48-01 1 Gasket 1,39

6 520 95 49-01 1 Diaphragm pump 1,39

7 520 75 98-01 1 Screw 1

8 520 97 86-01 1 Valve, throttle 1

9 516 93 60-01 1 Ball 1

10 516 93 59-01 1 Piston 1

11 516 92 73-01 1 Spring 1

12 520 95 70-01 1 Screen 1

13 522 63 20-01 1 Choke shaft 1

14 516 52 42-01 5 Washer 1

15 521 58 11-01 1 Lever 1

16 521 58 01-01 1 Spring choke shaft 1

17 522 64 62-01 1 Throttle schaft 1

18 516 84 39-01 1 Spring, throttle latch 1

19 516 21 70-01 4 Clip 1

20 516 34 29-01 1 Plug 1

21 516 98 00-01 1 Spring 1

22 521 08 54-01 1 Valve, inlet 1

23 516 95 69-01 1 Valve, choke 1

24 520 75 98-01 1 Screw 1

25 520 97 73-01 1 Screw 1

26 520 97 72-01 1 Lever 1

27 520 97 74-01 1 Pin 1

28 516 97 21-01 1 Gasket 1,39

29 522 64 84-01 1 Diaphragm carburetor 1,39

30 522 64 60-01 1 Cover 1

31 520 97 88-01 2 Screw kit 1

32 522 64 61-01 1 Screw 1

33 522 64 67-01 1 Bracket 1

34 522 64 56-01 2 Screw kit 1

35 520 75 98-01 3 Screw 1

36 522 64 59-01 1 Throttle link 1

37 522 64 64-01 1 Rod 1

38 520 97 63-01 1 Screw 1

39 522 64 02-01 1 Diaphragm kit

40 522 64 63-01 1 Body air valve 1

41 521 11 69-01 2 Cap 1

42 521 58 54-01 1 Needle 1

43 516 93 58-01 1 Needle 1
