Husqvarna T435 (2009) parts [3/27] Page a t435

Page A T435 BRAKE ASSY

Position Part nr. Quantity Description Kit

1 522 01 38-01 1 Brake assy

2 516 85 38-01 1 Gear 1

3 516 95 22-01 1 Screw 1

4 516 91 81-01 1 Tension knob 1

5 522 64 33-01 1 Plate 1

6 516 82 72-01 5 Screw 1

7 522 64 32-01 1 Spring 1

8 516 96 75-01 1 Bolt 1

9 516 96 76-01 1 Spacer 1

10 516 96 78-01 1 Spacer 1

11 516 96 74-01 1 Spring 1

12 521 02 54-01 1 Washer 1

13 520 96 86-01 1 Nut 1

14 522 63 98-01 1 weight 1

15 516 98 84-01 1 Spring 1

16 522 01 57-01 1 Hand guard 1

17 516 97 67-01 1 Pin 1

18 516 97 64-01 1 Lever 1

19 516 82 56-01 1 Arm 1

20 516 82 66-01 1 Spring 1

21 521 07 54-01 1 Pin 1

22 522 01 54-01 1 Brake cover 1

23 521 80 11-01 1 Brake band 1

24 523 08 06-01 1 Guide 1

25 503 22 00-01 1 Nut

26 522 63 52-01 1 Decal, clutch cover
