Husqvarna 235 (2008) parts [11/33] Page e1 235e 240e eps starter

Page E1

235e/240e

EPS STARTER

Pos. Description

Compl No.

(pos no.)

Part No. Qty Notes

1 SCREW SHOULDER 7,12 530-021179 1

2 STARTER HUB EPS 7,12 530-059677 1

3 SPRING EPS 7,12 530-021180 1

4 SCREW, ROPE RETAINER 7,12 530-016080 1

5 PULLEY- STARTER EPS 7,12 545-058201 1

6 SPRING- RECOIL 12 530-042095 1

7 KIT, EPS STARTER 235e/240e 12 530-071966 0 INCL. 1,2,3,4,5

8 BAFFLE 545-063801 1

9 FAN HOUSING 12 545-063701 1

10 HANDLE & ROPE assy 12 545-010010 1

11 SCREW, FAN HOUSING 12 530-016432 4

12 KIT, COMPLETE EPS 235e/240e 545-008024 0 INCL. 1,2,3,4,5,6,8,9,10,11

13 DECAL 235e 545-118502 1

14 DECAL 240e 545-118501 1
