Husqvarna 235 (2008) parts [27/33] Page l 235 235e 240 240e chassis hand guard

Page L

235/235e/240/240e

CHASSIS & HAND GUARD

Pos. Description

Compl No.

(pos no.)

Part No. Qty Notes

HANDGUARD 545-066701 1

BOSS SCREW, HANDGUARD 545-127301 1

REAR WALL 545-061201 1

SCREW, MTG REAR WALL 530-016064 1

GROMMET, REAR WALL 545-075401 1

PLATE BAR MOUNTING 545-071401 1

CAP, SPRING HANDGUARD 545-071301 1

SPRING, HANDGUARD POSITION 545-071201 1

11 CHASSIS ASSEMBLY 545-061101 0 INCL. 13-23, 25-27

BOLT, BAR 11 530-016133 2

ASSY, VENT LINE 11 545-033501 1

PLUG VENT (BRONZE) 11 530-029868 1

CHECK VALVE (DUCK BILL) 11 530-026119 1

LINE-RETURN PURGE 11 530-021132 1

FITTING- FUEL LINE 11 530-023877 1

ISOLATOR FILTER HOUSING 11 545-061901 1

ASSY-OIL/FUEL CAP W/RET. 11 545-070801 2

SCREW M5.28X1.81X16MM PLAS 11 530-015906 2

ASS'Y FRONT ISOLATOR 11 545-033801 1

REAR ISOLATOR SPRING 11 545-063101 1

ASSY- PICK-UP 11 530-095646 1

LINE, FUEL 11 545-078302 1

SCREW CATCHER 530-015814 1

HAIN CATCHER 530-029850 2

SPIKE 32 530-038990 1

SCREW SPIKE 32 530-016439 2

KIT SPIKE 530-014381 0 INCL 30,31
