Husqvarna 235 (2008) parts [5/33] Page b 235 240 chain brake assy 545 07 11 03

Page B

235/240

CHAIN BRAKE ASSY 545 07 11-03

Pos. Description

Compl No.

(pos no.)

Part No. Qty Notes

2 PIN, DOWEL 16 530-057950 1

3 ASSY, FRONT LINK 16 530-057940 1

4 M3.83 X 1.81 X 9 PLASTITE 16 530-015911 1

5 SPRING COMPRESSION 16 530-016415 1

6 SCREW BAR ADJUSTING 16 530-016110 1

7 RETAINER PUSH NUT 16 530-038593 1

8 PIN BAR ADJUST 16 530-015826 1

10 PIN, BAND RETAINER 16 530-015913 1

11 BRAKE BAND 16 530-057923 1

12 COVER, BRAKE BAND 16 545-071001 1

13 SCP#6-19 X .437 .PL. PAN. 16 530-016064 3

14 NUT, BAR MTG 530015917 2

15 DECAL 545-118701 1

16 CHAIN BRAKE ASS'Y FRT ADJ 545-071103 1 INCL. 2-13
