Chapter 1. 1-2
***Your monitor supports the following Tinys that can be installed in your monitor:
ThinkCentre M93p Tiny(Q87) √ ×
ThinkCentre M53 Tiny(Baytrail) √ ×
ThinkCentre Chromebox(Broardwell-U) × √
ThinkCentre M900 Tiny (Q170) √√
ThinkCentre M900x Tiny(Q170 65w) √√
ThinkCentre M700 Tiny(B150) √√
ThinkCentre M600 Tiny √√
ThinkCentre M600 Tiny Fanless √√
ThinkCentre M910q Tiny (Q270) √√
ThinkCentre M910x Tiny(Q270 65w) √√
ThinkCentre M910x Tiny(Q270
w/GPU)
√√
ThinkCentre M710q Tiny(B250) √√
ThinkCentre M715q Tiny(AMD) √√
ThinkCentre M625q(AMD) √√
ThinkCentre WS P320-P1000 √√
ThinkCentre WS P320-P600 √√
ThinkCentre M920x(Q370) 65W √√
ThinkCentre M920x-KT(Q370) GPU √√
ThinkCentre M920q(Q370) √√
(2)
1
