Chapter 1. 1-3
ThinkCentre M720q-KT(B360) √√
ThinkCentre M720q(B360) √√
ThinkCentre WS P330-P1000 √√
ThinkCentre WS P330-P620 √√
Before you install your Tiny into your monitor, ensure that the Tiny is listed above.
Install your computer into the TIO27
2When using "ALT+P" to power on Tiny, please Connect a Lenovo keyboard the USB port
shown as above on the rear of computer
3Press ALT+P on the keyboard to power on the computer and TIO27.
Note 1: ThinkCentre Tiny may also be powered on with the TIO27 power button. (See Figure
2)
Note 2: When connect many cables to ThinkCentre Tiny, it is recommended to do cable
management or open lift door.
Note 3: Some ThinkCentre Tiny can't be powered on with the TIO27, please press ALT+P on
the keyboard to power on computer.
Note 4: The Tinys are TIO27's accessory, you can purchase them on Lenovo website.
***Your monitor supports the following Tinys that can be installed in your monitor:
