Cunill Marfil Tron [12/28] Technical specifications

(nº12) MICHIGAN Model

H:700mm L:355mm W:210mm Wei: 18Kg

Number of motors: 1

Voltage:230v-110v-Frequency:50Hz-60Hz

Phases: 1(single)-Amperage: 3,1A - 6,82A

Power: 0,50/680

Condenser: 20nf-450v -80nf-400v

Speed:1300-1650 - Protection degree: IP21.

Motor equipped with Thermal Protector

Tempered Steel Grinding Wheels, 65mm.

Duration of Grinding Wheels:500kg Cof.B.

Hopper Capacity: 2 Kg.

Dispenser Capacity: Bags

Dispenser adjustment: NO.

Special Bags filling.

-Manual.models:3minutes working, 15 minu-

tes stop.

(nº12) MOVIE - “Silencer” Model

Al:660mm L:460mm W:265mm Wei: 18Kg

Number of motors: 1 (op) + 1motor-fan

Voltage: 230v-110v-Frequency: 50Hz-60Hz

Phases: 1(mono)-Amperage: 2,1A - 4,62A

Power:0,30/360

Condenser: 14nf-450v -55nf-400v

Speed:1300-1650. Protection degree: IP21

Maximum Continuous Service Time:30min.

Motor equipped with Thermal Protector

Tempered Steel Grinding Wheels, 65mm

Duration of Grinding Wheels:500kg

Cof.B.Capacidad tolva: 2 Kg.

Hopper Capacity: 600 Gr.

Dispenser adjustment: 5Gr - 12Gr.

On-Off: Automatic(Movie)

On-Off:Automatic every 8 coffees-Bi.motor

-Manual.models:3minutes working, 15 minu-

tes stop.

07 Technical Specifications
