4 Putting into operation
4.1 Switching on the appliance
u
Open the door.
u
Press the On/Off button
Fig. 2 (1)
.
w
The temperature display lights up. The interior
light goes on when the door is opened. The appli-
ance is switched on.
w
If “DEMO” is displayed, demo mode is activated.
Please contact the after sales service.
5 Control
5.1 Child proofing
The child-proofing function enables you to make
sure that the appliance is not inadvertently switched
off by playing children.
5.1.1 Setting the child lock
To activate the setting mode:
u
Press the SuperCool button
Fig. 2 (4)
for about 5 seconds.
w
The Menu symbol is shown on the display,
Fig. 2 (8)
.
w
c flashes on the display.
To switch on the function:
u
Confirm briefly with the SuperCool button
Fig. 2 (4)
.
w
c1 appears on the display.
u
Confirm briefly with the SuperCool button
Fig. 2 (4)
.
w
The child lock symbol,
Fig. 2 (9)
, lights up on the
display.
w
c flashes on the display.
w
The child lock function is switched on.
If the function is to be switched off:
u
Confirm briefly with the SuperCool button
Fig. 2 (4)
.
w
c0 appears on the display.
u
Confirm briefly with the SuperCool button
Fig. 2 (4)
.
w
c flashes in the display.
w
The child lock function is switched off.
To end the setting mode:
u
Briefly press the On/Off button
Fig. 2 (1)
.
w
The temperature display shows the temperature again.
5.2 Refrigerator compartment
The natural circulation of air in the refrigerator compartment
results in zones differing in temperature. It is coldest directly
above the vegetable drawers and at the rear wall. It is warmest
at the top front of the compartment and in the door.
5.2.1 Food refrigeration
Note*
The energy consumption increases and the cooling perform-
ance decreases if the ventilation is inadequate.
u
Always keep the air slits of the fan free.
u
Store perishable food such as ready-to-serve dishes, meat
products and sausages in the coldest zone. Place butter and
preserves in the upper area and in the door (see Appliance
at a glance).
u
Use recyclable plastic, metal, aluminium and glass
containers and cling film for wrapping.
u
Always store liquids and food which is subject to odour or
taste transfer in closed containers or cover them.
u
Foods which give off a large amount of ethylene gas and
delicate foods, such as fruit, vegetables, salad, should
always be stored separately or wrapped so as not to reduce
the storage life; e.g. do not store tomatoes together with
kiwis or cabbage.
for appliances from 1218 mm in height, the following applies:
u
Use the front area of the refrigerator compartment floor only
for briefly putting down cooled products, e.g. when rear-
ranging and sorting. However do not leave cooled products
there otherwise they may be pushed back or tipped over
when the door is closed.
u
Do not store food too close together to enable good air
circulation.
5.2.2 Setting the temperature
The temperature depends on the following factors:
-
the frequency of opening the door
-
the room temperature of the installation location
-
the type, temperature and quantity of the food
Recommended temperature setting: 5 °C
An average temperature of approx. -18 °C is then established
in the freezer compartment.*
The temperature can be adjusted continually. Once the 1 °C
setting is reached, the sequence starts again at 9 °C .
u
Call up temperature function: press the setting
button
Fig. 2 (3)
.
w
The previously-set value will flash in the temper-
ature display.
u
Change the temperature in 1 °C steps: Press the
setting button
Fig. 2 (3)
until the required
temperature is indicated in the temperature
display.
u
Change temperature continually: hold down
setting button.
w
During adjustment the value flashes on the
display.
w
The new setting is adopted approx. 5 seconds after the last
time the button was pressed and the set temperature
displayed again. The temperature in the interior gradually
adjusts to the new value.
5.2.3 SuperCool
With SuperCool you switch to the highest cooling
performance to reach lower cooling temperatures.
Use SuperCool, to rapidly cool large amounts of
food.
When SuperCool is activated, the fan* may run. The appliance
operates with maximum cooling performance, which means
that the noise of the refrigeration unit may be temporarily
louder.
The SuperCool function uses slightly more energy.
Cooling with SuperCool
u
Briefly press SuperCool button
Fig. 2 (4)
.
w
The SuperCool symbol
Fig. 2 (5)
lights up in the display.
w
The cooling temperature drops to the coldest value.
SuperCool is activated.
w
SuperCool is automatically deactivated after 12 hours. The
appliance continues to operate in the energy-saving, normal
mode.
To prematurely deactivate SuperCool
u
Briefly press SuperCool button
Fig. 2 (4)
.
w
The SuperCool symbol
Fig. 2 (5)
goes out in the display.
w
SuperCool is deactivated.
Putting into operation
* Depending on model and options 5
