5.2.9 Egg tray*
You can take out and rotate the egg tray. You can use the two
parts of the egg tray to mark different use-by dates, for
example.
u
Use the top part to store e.g. chicken eggs.
u
Use the bottom part to store quails' eggs.
5.2.10 Vegetable drawers*
Fig. 8
5.2.11 BioCool box*
Controlling humidity
u
Low humidity: Move
the slide controller
forward.
u
High humidity:
Move the slide controller
back.
Removing the BioCool box
BioCool box without pull out:
Fig. 9
BioCool box on roller plates:
Fig. 10
u
BioCool box and roller plates can be removed for cleaning.
BioCool box on extendible rails:
Fig. 11
u
Pull out the drawer, lift it at the back and remove it from the
front.
u
Slide the rails in.
u
BioCool box can be removed for cleaning.
5.3 Freezer compartment*
You can store frozen food for several months, make ice cubes
and freeze fresh food in the freezer compartment at a tempera-
ture of -18 °C and lower.
The air temperature in the compartment, measured by ther-
mometer or other instruments, may fluctuate.
5.3.1 Freezing food*
2 kg fresh food/24 h is the maximum weight which can be
frozen.
CAUTION
Risk of injury due to broken glass!
Bottles and cans containing drinks may burst when being
frozen. This applies particularly to sparkling drinks.
u
Do not freeze bottles and cans containing drinks!
u
4 h before freezing food, set the temperature to 5 °C or
colder.
In order that the food is rapidly frozen through to the core, do
not exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg
- Meat up to 2.5 kg
u
Pack the food in portions in freezer bags, reusable plastic,
metal or aluminium containers.
u
Spread the food over the shelf. Do not allow it to contact and
thaw items that are already frozen.
u
Set the temperature back again 24 h after placing the food
inside.
5.3.2 Storage times*
Guide times for storing various types of food in the
freezer compartment:
Ice cream 2 to 6 months
Sausage, ham 2 to 6 months
Bread, bakery products 2 to 6 months
Game, pork 6 to 10 months
Control
* Depending on model and options 7
