10
Freezing
The maximum amount of food wich can be frozen in 24 hours is
shown on the type plate “Freezing capacity” 4. This amount
varies according to the model and climate rating. This maximum
quantity of frozen goods varies depending on model and
climate class.
Freezing with SuperFrost
Fig. A1/5
W Press SuperFrost button 5
briefly, so that the LED lights up.
The corresponding symbol ap
-
pears in the display.
W With a smaller amount of food to
be frozen, wait/pre-freeze for ap-
prox 6 hours - normally sufficient,
with the maximum quantity, see freezing capacity on rating
plate, approx. 24 hours.
W Then insert the fresh food. SuperFrost switches off automati-
cally after approximately 65 hours. Freezing is finished when
the SuperFrost button has gone out - the appliance is now
operating in normal energy-saving mode.
NB: When you press the Superfrost button, the compressor
might not switch on for up to 8 minutes. This is due to the inte-
grated rise-delay switch which is designed to increase the life
span of the refrigeration unit.
Note: To save energy, "Superfrost" can be switched off before
the 65 hours have elapsed by pressing the SF button again.
Ensure that the temperature is at least -18°C.
You should not switch on the Superfrost function:
- when placing frozen food in the freezer;
- when freezing up to approx. 2 kg fresh food daily.
Making ice cubes
• Fill the ice-cube tray three-quarters
full with water and freeze.
• The ice cubes can be removed from
the tray by twisting or by holding
upside down for a short time under
running water.
Cooling
Example of arrangement
!
Butter, Cheese
"
Eggs
§
Bottles, Cans, Tubes
$
Frozen Food, Ice Cubes
%
Meat, Sausages, Dairy
Products
&
Baked Goods, Pre-Cooked
Meals, Drinks
/
Fruit, Vegetables, Salad,
Note
• Only store high-percentage al-
cohol in tightly sealed, upright
containers.
• Fruit, vegetables and salad
can be stored unpacked in the
bins.
• Reuseable plastic, metal, alumi
-
nium and glass containers can be used for packaging.
Refrigerating with fan
(depending on model and options)
This achieves a relatively even temperature distribution over
at all storage levels; all foods are equally cool, at an adjustable
temperature. Due to the enforced air circulation, the various
temperature ranges of normal operation are raised.
It is generally recommended:
- with high room temperature (abo
-
ve approx. 30 °C),
- with high humidity, e.g. on sum-
mer days.
Switching on and off, Fig. A1:
Turn on fan switch 4.
The indicator lamp in the switch will
light up.
The corresponding symbol appears
in the display.
Note: the fan may also run when the fan function is switched off. This
is a functional feature and completely normal if the room temperature
is below 18°C when the SuperFrost function is switched on.
Note
- Place food inside the appliance as shown in the diagram. This
allows the appliance to save energy during operation.
- Shelves, drawers and baskets are arranged for optimum en-
ergy efficiency on delivery.
Interior light
Light-bulb specifications: 25 W (never use a bulb rated at
more than 25 W). The voltage should agree with the details on
the type plate. Socket: E 14.
Replacing the bulb:
Pull out the mains plug or remove/unscrew the fuse.
• Push the sides 1 of the lamp cover together according to Fig.
F1, unlatch and detach 2.
• Replace the light bulb according to Fig.
F2. When inserting
the new bulb, make sure the seal is correctly positioned in the
socket.
• Attach the cover at the rear again and lock into place on sides.
