Falmec Laguna 60 vetro (800) Nero STEC [24/80] Mounting instructions range hoods with box

claims all liability for any damage that may be directly or indirectly caused

to people, things and animals due to the failure to follow all the instructions

provided in this booklet and above all the warnings relating to the installa-

tion, operation and maintenance of the appliance.

WARRANTY

The new equipment is covered by warranty.

The warranty conditions are provided by the distributor.

The manufacturer is not liable for any inaccuracies in this booklet resulting

from printing or transcription errors. The manufacturer reserves the right to

modify its products as it considers necessary or in the interests of the user,

without compromising their essential safety and operating characteristics.

MOUNTING INSTRUCTIONS, RANGE

HOODS WITH BOX

Step 1

- Rest the support bar against the wall (A-Fig. 1) at a height from the cooktop

determined by the sum of the distance X+Y+320 mm.

- Check the horizontal alignment with a spirit level and mark the 2 holes to be

drilled at the ends of the bar.

- Drill the holes, insert 2 x 8mm dia. screw anchors, and fasten the bar using

the corresponding screws.

Step 2

- Hook the range hood to the support bar (Fig. 2).

- Adjust the alignment of the range hood using the screws on the brack-ets

(Fig. 2). The top screw (B) adjust the distance from the wall, the bottom

screw (C) adjust the height.

Step 3

- Fix the hood on the wall with an expansion anchor and with a screw, using

the holes on the back side of the hood or with the cover brackets, in order to

prevent it from detaching due to the pressure below.

In case of the suction version, connect the outlet fitting of the fan to the ex-

ternal discharge with appropriate pipes.

- Carry out the electrical connections after having disconnected the hood po-

wer supply.

Step 4

- Insert the extension cable (H) in the cook hood stack (G) and fix the assembly

on the hood body using the 8 screws as shown in (V1).

- Unfold the extension cable (H) until reaching the required length.

- Once the ideal position is reached, lay the bracket (L) on the wall and check

the horizontal alignment using a spirit level and mark 2 holes at the edges.

- Drill the holes and insert 2 expansion anchors with a diameter of 4mm and

fasten the bracket (L) with the screws.

- Tighten the extension cable (H) to the bracket (L) by means of the screws (M)

Power the hood in compliance with the regulations in force (section D).
