Parent unit

Operation on rechargeable batteries

The parent unit comes with two NiMH AAA 850mAh batteries.

Charge the parent unit before you use it for the rst time or when the battery light indicates that

the batteries are low. The battery light ashes red when the batteries are low. The battery light starts

to ash red 30 minutes before the batteries are completely empty.

Note: If the batteries are completely empty, the parent unit automatically switches off and loses contact

with the baby unit.

1 Remove the lid of the compartment for the rechargeable batteries (Fig. 6).

2 Insert the rechargeable batteries (Fig. 7).

Note: Make sure the + and - poles of the batteries point in the right direction.

3 Reattach the lid (Fig. 8).

4 Put the small appliance plug in the parent unit and put the adapter in a wall socket (Fig. 9).

5 Leave the parent unit connected to the mains until the batteries are fully charged.

, During charging, the battery light lights up red continuously.

, When the batteries are fully charged, the battery light lights up green continuously.

- When you charge the parent unit for the rst time or after a long period of disuse, switch it

off and let it charge continuously for at least 10 hours.

- Charging normally takes 8 hours, but it takes longer when the parent unit is switched on while

charging. To keep the charging time as short as possible, switch off the parent unit during

charging.

- When the batteries are fully charged, the parent unit can be used cordlessly for up to 24 hours.

Note: When the parent unit is charged for the rst time, the operating time is less than 24 hours. The

batteries only reach their full capacity after you have charged and discharged them four times.

Note: When the parent unit is not connected to the mains or even when the parent unit is switched off,

the batteries gradually discharge.

using the appliance

1 Place the parent unit and the baby unit in the same room to test the connection (Fig. 10).

Make sure the baby unit is at least 1 metre/3.5 feet away from the parent unit.

2 Press and hold the on/off button 3 on the baby unit until the green power-on light goes

on. (Fig. 11)

Note: The power-on light always lights up green, even when there is no connection with the parent unit.

, The nightlight lights up briey and then goes out again.

, The battery light T lights up briey and then goes out again. (Fig. 12)

3 Press and hold the on/off button 3 on the parent unit until the sound level lights light up

briey. (Fig. 13)

, The battery light briey lights up red and then continuously is on (Fig. 14).

, The LINK light ashes red. (Fig. 15)

, The LINK light on the parent unit turns green and lights up continuously when a connection

has been established between the baby unit and parent unit (Fig. 16).

, If no connection is established, the LINK light on the parent unit stops ashing and lights up

red. The parent unit beeps from time to time. (Fig. 17)
