[C-2-2] MUST have a TYPE_ACCELEROMETER_UNCALIBRATED with the same quality

requirements as TYPE_ACCELEROMETER .

[C-2-3] MUST have a TYPE_GYROSCOPE sensor which:

MUST have a measurement range between at least -1000 and +1000 dps.

MUST have a measurement resolution of at least 16 LSB/dps.

MUST have a minimum measurement frequency of 12.5 Hz or lower.

MUST have a maximum measurement frequency of 400 Hz or higher.

MUST have a measurement noise not above 0.014°/s/√Hz.

SHOULD have a stationary bias stability of < 0.0002 °/s √Hz from 24-hour

static dataset.

SHOULD have a bias change vs. temperature of ≤ +/- 0.05 °/ s / °C.

SHOULD have a sensitivity change vs. temperature of ≤ 0.02% / °C.

SHOULD have a best-fit line non-linearity of ≤ 0.2%.

SHOULD have a noise density of ≤ 0.007 °/s/√Hz.

SHOULD have white noise spectrum to ensure adequate qualification of

sensor’s noise integrity.

SHOULD have calibration error less than 0.002 rad/s in temperature range 10

~ 40 ℃ when device is stationary.

[C-2-4] MUST have a TYPE_GYROSCOPE_UNCALIBRATED with the same quality

requirements as TYPE_GYROSCOPE .

[C-2-5] MUST have a TYPE_GEOMAGNETIC_FIELD sensor which:

MUST have a measurement range between at least -900 and +900 uT.

MUST have a measurement resolution of at least 5 LSB/uT.

MUST have a minimum measurement frequency of 5 Hz or lower.

MUST have a maximum measurement frequency of 50 Hz or higher.

MUST have a measurement noise not above 0.5 uT.

[C-2-6] MUST have a TYPE_MAGNETIC_FIELD_UNCALIBRATED with the same quality

requirements as TYPE_GEOMAGNETIC_FIELD and in addition:

MUST implement a non-wake-up form of this sensor with a buffering capability

of at least 600 sensor events.

SHOULD have white noise spectrum to ensure adequate qualification of

sensor’s noise integrity.

[C-2-7] MUST have a TYPE_PRESSURE sensor which:

MUST have a measurement range between at least 300 and 1100 hPa.

MUST have a measurement resolution of at least 80 LSB/hPa.

MUST have a minimum measurement frequency of 1 Hz or lower.

MUST have a maximum measurement frequency of 10 Hz or higher.

MUST have a measurement noise not above 2 Pa/√Hz.

MUST implement a non-wake-up form of this sensor with a buffering capability

of at least 300 sensor events.

MUST have a batching power consumption not worse than 2 mW.

[C-2-8] MUST have a TYPE_GAME_ROTATION_VECTOR sensor which:

MUST implement a non-wake-up form of this sensor with a buffering capability

of at least 300 sensor events.

MUST have a batching power consumption not worse than 4 mW.

[C-2-9] MUST have a TYPE_SIGNIFICANT_MOTION sensor which:

MUST have a power consumption not worse than 0.5 mW when device is static

and 1.5 mW when device is moving.
