OMNITRONIC CMP-102 [25/30] Set up

00052162.DOC, Version 1.0

25/30

5. SET UP

5.1 Installation

Install the unit on a plane surface or in your rack. For 19" (483 mm) rack installation 1 unit is required. When

mounting the unit into the rack, please make sure that there is enough space around the device so that the

heated air can be passed on. Steady overheating will damage your device. You can fix the unit with four

screws M6 in the rack.

5.2 Connections

Prior to making or changing any connections, switch off the CMP-102 and the units to be connected.

1. Connect subsequent units with line level inputs (e.g. amplifier or mixer) to the balanced XLR output

and/or to the unbalanced RCA output. Make sure that the right/left occupation is the same at the units.

The output volume can be adjusted with the control MASTER LEVEL.

2. For sound recordings, connect the recording unit to the recording output REC. The recording level is

independent of the position of the master control. With an audio interface such as the OMNITRONIC

ADI-002PL you can also digitize the analog output signal of the CMP-102 and transfer it to a

computer with USB 1.1 or 2.0 connection.

3. The music of the CD can be monitored ahead of the master control MASTER LEVEL via stereo

headphones. Connect the headphones to the 3.5 mm jack PHONES on the front panel. The headphone

volume can be adjusted with the control CUE LEVEL.

4. Use the supplied power cable to connect the CMP-102 to the mains.

If the device will be directly connected with the local power supply network, a disconnection switch with a

minimum opening of 3 mm at every pole has to be included in the permanent electrical installation. The device

must only be connected with an electric installation carried out in compliance with the IEC standards. The

electric installation must be equipped with a Residual Current Device (RCD) with a maximum fault current of

30 mA.

5.3 Remote control

1. To insert the batteries, remove the cover on the rear side of the remote control.

2. Insert two 1.5 V micro batteries (type AAA) as indicated in the battery compartment. Close the

compartment again with the cover.

3. If the remote control is not used for a longer period (approx. 1-2 weeks), please remove the batteries to

prevent damage in case of battery leakage. Please refer to further explanations in chapter Safety

Instructions.

CAUTION!

Danger of explosion when battery is replaced improperly.

Only replace by the same type or similar types recommended by the manufacturer.

Remove empty battery in accordance with the instructions of the manufacturer.

BATTERY DISPOSAL NOTICE

Please dispose of discharged batteries properly.

Batteries are hazardous waste and should not be disposed of with regular domestic waste!

Please take discharged batteries to a collection center near you.
