1 & 5. LEFT/RIGHT LINK: sends to the output the same signal coming from
LEFT/RIGHT INPUT connector. This allow the cascade connection of different
devices to the same sound source.
2 & 6. LEFT/RIGHT INPUT: XLR input socket for connection of the signal to be
amplified.
3. RS485 OUT : Etherconn connector to connect to the digital network. Use to
connect to the RS485 IN input of the next speaker along the daisy chain.
4. RS485 IN : Etherconn connector to connect to the digital network. Plug here
the cable coming from the RS485 OUT connector of the previous speaker in
the daisy-chain, or the USB-485 interface (D:SP INTERFACE) output if the
speaker is the first in the chain.
7. LEDs:
- ON LED: indicates that the speaker is On.
- Prot. LED: indicates that the internal amplifier switched to protection mode
due to a fault of the amplifier itself or of the connected speakers (please call
the technical support).
- Temp. LED: indicates that the internal amplifier switched to protection
mode due to excessive heating. In this condition, the amplifier supply half
the normal power. Please reduce the input signal to allow the restore of
normal load conditions.
- Comp. LED: indicates activity of the compressor. If the signal passes over a
safety threshold, the compressor guarantees a good quality playback without
acoustic distortion, damping the appropriate signal frequencies. The system
operates in total safety. If the LED is constantly On, there is an excess of
signal. In this case, please reduce the incoming signal level.
- Sign. LED: indicates that the signal is present.
8. Gain: to adjust the signal gain in range from -35dB to 0dB.
9. Mains In: connect the mains cable supplied from the factory with the
loudspeaker to this socket.
10 & 12. AC Power Out: easily connect up to other two VERSE speakers to the
mains. Pay attention not to exceed the limit reported on the chassis near to
the connectors.
11. POWER: Switches the power on/off.
