En-11
Saving a Scene Saving a scene to the SCENE 1–4 buttons
Saving a Scene
Saving a scene to the SCENE 1–4
buttons
You can save the sound settings on the VOX Continental as
scenes. There are a total of 16 scenes (4 scenes × 4 banks).
The settings that can be saved in a scene include the part select
buttons, each sound part, the touch sensors, and EFFECT
control (except for the EQ).
Note: The following settings are not saved in scenes.
EQ, VOLUME knob, VALVE DRIVE knob and button,
DYNAMICS knob and button, CONTROL button, bend lever
1 Press the WRITE button.
The SCENE 1–4 buttons will blink.
2 Press the BANK , buttons to select the bank where the
scene will be saved.
The A–D LEDs will light.
3 Press a button from SCENE 1–4 to select the scene to be
registered.
Only the SCENE button that you press will blink.
If you press the EXIT button, the save operation will be
cancelled.
4 Press the same SCENE 1–4 buttons again to save the sound
in the bank and scene that you specified.
The button corresponding to the scene you saved (SCENE
1–4) will blink.
You can also press the WRITE button to save the scene.
Scenes can also be saved to USB storage devices (commercially
available). (See page 23)
Listening to the demo
songs
Playing back the demo songs
The VOX Continental comes with 16 demo songs that are
appropriate for each sound on the keyboard.
Organ sounds: 4, electric piano sounds: 4, piano sounds: 4,
keyboard/layer sounds: 4
1 Hold down both the BANK and buttons.
Release the buttons once the demo song starts playing.
The first song for the ORGAN part will play (the SCENE 1
and ORGAN buttons will blink).
2 Select the demo song for the sound you want to hear, by
using the part select buttons (ORGAN, E. PIANO, PIANO
or KEY/LAYER).
For instance, if you want to hear a demo song with the
piano sound, press the PIANO part select button. The first
song for PIANO sounds will play (the PIANO and SCENE
1 buttons will blink).
3 Select the four demo songs for each sound by using the
SCENE 1–4 buttons (the button you press will blink).
When the song ends that is currently playing, the next
song will automatically begin. All songs will play back
endlessly, in order.
Press a blinking SCENE button (indicating the song that is
being played back) to restart playback of that song from
the beginning.
Press a different SCENE button to stop playback of the
current song. The song corresponding to the SCENE
button you press will start playing back.
4 Press the EXIT button to return to normal play mode.
If a demo song is being played back when you press EXIT,
the song will stop.
2
3, 4
1, 4
1
23
4
