• Automatic Plug-in Focus and device auto-connect for A-Series keyboards when used with
Ableton Live.
• It is now possible to enter PLUG-IN from MIDI on A-Series keyboards.
• Accessibility for A-Series keyboards.
2.5. Box Contents
The box contains the following items:
• KOMPLETE KONTROL keyboard
• USB cable
• Information flyer providing:
• the hardware serial number of the KOMPLETE KONTROL keyboard
• a web link for downloading the KOMPLETE KONTROL software and the KOMPLETE SE-
LECT software bundle
• Safety Instructions flyer
2.6. System Requirements
For KOMPLETE KONTROL to fully function as indented, your system needs to meet certain re-
quirements. The latest KOMPLETE KONTROL system requirements and compatibility information
is available here:
https://www.native-instruments.com//komplete-kontrol-a25-a49-a61/specifications/
KOMPLETE
KOMPLETE KONTROL is optimized for use with KOMPLETE SELECT, KOMPLETE and KOM-
PLETE ULTIMATE.
The latest KOMPLETE system requirements and compatibility information is available here:
http://www.native-instruments.com/products/komplete/
2.7. Accessibility
KOMPLETE KONTROL offers a set of accessibility features for visually-impaired users. These are
focused exclusively on the KOMPLETE KONTROL keyboard itself and include speech output via
your computer for the following features:
• Perform, Transpose, Page left / right, and key navigation buttons.
• All Browser functions.
• The current edit mode, including the Plug-in Panel and the Perform panel (Scale, Arp).
• Names of parameters and parameter sections when touching knobs, including all edit modes.
The accessibility features are particularly useful when combined with KOM-
PLETE KONTROL’s host integration and Apple VoiceOver in Apple Logic Pro X and
GarageBand.
Welcome to KOMPLETE KONTROL
5
