• Mute
• Solo
The Preset buttons are located to the bottom right of the Perform and Edit section, above the Solo
and Mute buttons. The four buttons are arranged in a column.
The buttons are (from top to bottom):
• PRESET Up
• PRESET Down
The Control section is located in the center of the KOMPLETE KONTROL keyboard. It contains
eight knobs. The knobs are arranged in a row directly above the keybed.
The Navigation buttons are on the top right of the KOMPLETE KONTROL keyboard. The three
buttons are arranged in one row, (from left to right):
• BROWSER
• PLUG-IN
• TRACK
The 4-D encoder is located directly below the Navigation buttons.
The Transpose buttons are located at the far left of the keyboard next to the keybed and directly
above the Pitch and Modulation wheels. The two buttons are arranged in a row.
The buttons are (from left to right):
• OCT Down / FIXED VEL (TS Mode)
• OCT Up
2.7.2. Activating Accessibility Features
In order to activate or deactivate the accessibility features from the KOMPLETE KONTROL key-
board while the KOMPLETE KONTROL software is running:
1. Press and hold the SHIFT button on the top left of the keyboard.
2. While holding SHIFT, press the IDEAS button, located third to the right, in the second row on
the keyboard.
The speech output confirms that the accessibility features have been activated or deactiva-
ted.
The accessibility features are designed to be used with the KOMPLETE KONTROL
plug-in. However, the KOMPLETE KONTROL stand-alone application must be
opened after initial installation and after installing additional Instruments and Effects.
This will ensure that all Instruments, Loops, One-shots and Effects are displayed
correctly in the KOMPLETE KONTROL Browser.
