2.7.1. Keyboard Overview
The buttons and knobs on the KOMPLETE KONTROL keyboard are organized in the following
groups:
• Perform and Edit section
• Transport section
• Solo and Mute buttons
• Preset and Page buttons
• Control section
• Navigation and Mode buttons
• 4-Directional Push Encoder (referred to as the 4-D encoder)
• Transpose and Fixed Velocity buttons
The Perform and Edit section is located at the top left of the keyboard. It contains six buttons that
are arranged in two rows.
The buttons in the first row are (from left to right):
• SHIFT
• SCALE (Edit)
• ARP (Edit)
The buttons in the second row are (from left to right):
• UNDO (Redo)
• QUANTIZE
• AUTO
The Transport section is located directly below the Perform and Edit section. It contains six buttons
that are arranged in two rows.
The buttons in the first row are (from left to right):
• LOOP
• METRO
• TEMPO
The buttons in the second row are (from left to right):
• PLAY (Restart)
• REC (Count-In)
• STOP
The Solo and Mute buttons are located to the right of the Transport section. The two buttons are
arranged in a row.
The buttons are (from left to right):
Welcome to KOMPLETE KONTROL
6
