Roland DJ-202 [4/12] Panel descriptions
![Roland DJ-202 [4/12] Panel descriptions](/views2/2007997/page4/bg4.png)
4
Panel Descriptions
The top panel of the DJ-202 is divided into three sections by function: browser, deck, and mixer.
Phones jack is located on the front side, and input/output jacks are located on the rear side.
For details about each part, refer to the DJ-202 owner’s manual and the Serato DJ Intro manual.
1
Browser section
2
Deck section
3
Mixer section
1
2
2
3
Browser Section
Use these controls to operate Serato DJ Intro and load songs.
2
1
1
1
[LOAD] buttons
Load a song selected on Serato DJ Intro into a deck.
[SHIFT] + [LOAD] Sorts the song library by SONG or BPM.
2
Rotary selector
Turn this knob to move the cursor up/down. Press this knob to move the
cursor to a lower level.
[SHIFT] + Press the knob Moves the cursor to a higher level.
