5
Panel Descriptions
Deck Section
The deck sections located at the left and right control four decks (left: decks 1 and 3, right: decks 2 and 4).
1
2
3
4
5
6
7
8
9
10
11
12
13
1
Jog dial
Controls scratch and pitch bend (playback speed adjustment).
Rotate the top surface
Performs scratch if the VINYL mode is on, or performs pitch
bend if the button is o.
Rotate the outer edge Performs pitch bend.
[SHIFT] + rotate the top surface Rapidly moves the playback location.
2
[VINYL] button
Turns VINYL mode on/o.
3
[SHIFT] button
You can recall other functions by holding down this button and pressing
another button.
4
[SYNC] button
Automatically matches the tempo (pitch) of multiple songs.
[SHIFT] + [SYNC] Cancels SYNC.
5
[CUE
u
] button
Species, plays, or recalls a temporary cue point.
6
[
r
] button
Plays or pauses the song.
[SHIFT] + [
r
]
Returns to the temporary cue point, and plays.
7
Pad Mode select
Here you can select the control mode of the performance pads.
[HOT CUE] button
Selects hot cue mode.
[LOOP] button
Selects loop mode.
[SEQUENCER] button
Selects sequencer mode.
[SHIFT] + [SEQUENCER]
Selects pattern mode.
Switches the sequencer’s pattern.
[SAMPLER] button
Selects sampler mode.
8
Performance pads
Use these pads to perform in the pad mode that you’ve selected.
9
PARAM area
Here you can specify the value of the parameter that’s operated by the
performance pads.
10
[KEY LOCK] button
Turns the key lock function on/o.
[SHIFT] + [KEY LOCK] Species the variable range of the Tempo slider.
11
[DECK 3], [DECK 4] buttons
Switch the deck (left: decks 1 and 3, right: decks 2 and 4) to be operated.
12
Tempo slider
Adjusts the playback speed of the song.
13
FX 1, FX 2 area
Here you can adjust the eects (FX 1: decks 1 and 3, FX 2: decks 2 and 4).
[LEVEL] knob
Adjust the character of the eect.
[SHIFT] + [LEVEL] knob Adjusts the time for which the eect is applied.
Eect buttons [1]–[3]
Turn the eect on/o.
[SHIFT] + Eect button Changes the eect type.
[TAP] button
The interval at which you press this button (tap tempo) species the
reference tempo of the eect.
If you long-press the button, the specied tempo is reset.
