RME M-32 DA [32/57] General

User’s Guide M-32 DA © RME

15.5 MIDI

• 16 channels MIDI

• 5-pin DIN jacks

• Optocoupled, ground-free input

MADI

• Invisible transmission via User bit of channel 56 (48k frame)

15.6 General

• Dimensions including rack ears (WxHxD): 483 x 88 x 242 mm (19" x 3.46" x 9.5")

• Dimensions without rack ears/handles (WxHxD): 436 x 88 x 235 mm (17.2" x 3.46" x 9.3")

• Temperature range: +5° up to +50° Celsius (41° F up to 122°F)

• Relative humidity: < 75%, non condensing

M-32 DA

• Power supply: Internal switching PSU, 100 - 240 V AC, 40 Watt

• Typical power consumption: 23 Watt

• Max. power consumption: < 30 Watt

• Weight: 3 kg ( 6.6 lbs)

M-16 DA

• Power supply: Internal switching PSU, 100 - 240 V AC, 40 Watt

• Typical power consumption: 15 Watt

• Max. power consumption: < 20 Watt

• Weight: 2.5 kg ( 5.5 lbs)

15.7 Firmware

The M-Series is internally based on programmable logic. By re-programming of a little compo-

nent called Flash-PROM, both function and behaviour of the unit can be changed at any time.

At the time of writing this manual, M-32 DA and M-16 DA are shipping with firmware 1.5. The

firmware version is displayed after power on for about one second on the level meters of the M-

series units.

Firmware 1.5: Initial release

Firmware 2.1: The temperature inside the unit can be read via MIDI. The fan operation can be

changed via MIDI.

15.8 MADI User Bit Chart

• RS-232: channels 1 to 9 (passed-through by the M-series)

• ADC: channel 19

• MIDI: channel 56 (48k) / 28 (96k)
