User's Guide ADI-6432 © RME
14.6 Firmware
The ADI-6432's main part has been realized using programmable logic. By re-programming of a
little component called Flash-PROM, both function and behaviour of the unit can be changed at
any time.
At the time of writing this manual, the unit is shipped with firmware 1.4. The firmware version is
displayed after power on for about one second by the SYNC and AUDIO LEDs of the AES
INPUT STATE section.
14.7 Connector Pinouts
The 25 pin D-sub connector provide four AES inputs and outputs each. The pinout uses the
widely spread Tascam scheme, which is also used by Digidesign.
Tascam / Digidesign:
Signal In
1/2+
In
1/2-
In
3/4+
In
3/4-
In
5/6+
In
5/6-
In
7/8+
In
7/8-
D-Sub 24 12 10 23 21 9 7 20
Signal Out
1/2+
Out
1/2-
Out
3/4+
Out
3/4-
Out
5/6+
Out
5/6-
Out
7/8+
Out
7/8-
D-Sub 18 6 4 17 15 3 1 14
GND is connected to pins 2, 5, 8, 11, 16, 19, 22, 25. Pin 13 is not connected.
The Yamaha pinout is quite popular as well. When building a D-sub to D-sub adapter or con-
nection cable, please make sure that the connectors are clearly labelled with Tascam and Ya-
maha. The cable can only be used when the Tascam side is connected to a Tascam connector,
and the Yamaha side is connected to a Yamaha connector.
Yamaha:
Signal In
1/2+
In
1/2-
In
3/4+
In
3/4-
In
5/6+
In
5/6-
In
7/8+
In
7/8-
D-Sub 1 14 2 15 3 16 4 17
Signal Out
1/2+
Out
1/2-
Out
3/4+
Out
3/4-
Out
5/6+
Out
5/6-
Out
7/8+
Out
7/8-
D-Sub 5 18 6 19 7 20 8 21
GND is connected to pins 9, 10, 11, 12, 13, 22, 23, 24, 25.
