User's Guide ADI-6432 © RME
33
The same is true for a direct adapter cable Tascam D-sub to Euphonix D-sub.
Euphonix:
Signal In
1/2+
In
1/2-
In
3/4+
In
3/4-
In
5/6+
In
5/6-
In
7/8+
In
7/8-
D-Sub 15 2 4 16 18 5 7 19
Signal Out
1/2+
Out
1/2-
Out
3/4+
Out
3/4-
Out
5/6+
Out
5/6-
Out
7/8+
Out
7/8-
D-Sub 21 8 10 22 24 11 13 25
GND is connected to pins 3, 6, 9, 12, 14, 17, 20, 23. Pin 1 is not connected.
AES/EBU
The XLR connectors are wired according to AES3-1992:
1 = GND (shield)
2 = Signal
3 = Signal
AES/EBU and SPDIF are biphase modulated signals, therefore polarity doesn't matter. Pins 2
and 3 are neither hot nor cold, they carry the same signal. But as AES3 uses a balanced trans-
mission they are inverted in polarity.
RS-232
The 9-pin D-Sub Connector is wired according to industry standard:
Signal In (Rx) Out (Tx) GND NC
Sub-D 2 3 5 9
Internally connected are pins 1 with 6 and 4, and pin 7 with 8.
1.8 MADI User Bit Chart
RS-232: channels 1 to 9
ADC: channel 19
MIDI: channel 56 (48k) / 28 (96k)
