User's Guide ADI-6432 © RME
41
17.4 Table
No. No. Name
Set
Value
Value
Resp. Data bytes
00h 0 settings byte 1 x x hex coded value of byte (see below)
01h 1 settings byte 2 x x hex coded value of byte (see below)
02h 2 info byte 1 x hex coded value of byte (see below)
03h 3 info byte 2 x hex coded value of byte (see below)
04h 4 info byte 3 x hex coded value of byte (see below)
05h 5 MADI audio 1..4 x bit 0..3 = audio 1..4, bit 4..7 = 0
06h 6 MADI audio 5..8 x bit 0..3 = audio 5..8, bit 4..7 = 0
07h 7 MADI audio 9..12 x bit 0..3 = audio 9..12, bit 4..7 = 0
08h 8 MADI audio 13..16 x bit 0..3 = audio 13..16, bit 4..7 = 0
09h 9 MADI audio 17..20 x bit 0..3 = audio 17..20, bit 4..7 = 0
0Ah 10 MADI audio 21..24 x bit 0..3 = audio 21..24, bit 4..7 = 0
0Bh 11 MADI audio 25..28 x bit 0..3 = audio 25..28, bit 4..7 = 0
0Ch 12 MADI audio 29..32 x bit 0..3 = audio 29..32, bit 4..7 = 0
0Dh 13 AES lock 1..4 x bit 0..3 = lock 1..4, bit 4..7 = 0
0Eh 14 AES lock 5..8 x bit 0..3 = lock 5..8, bit 4..7 = 0
0Fh 15 AES lock 9..12 x bit 0..3 = lock 9..12, bit 4..7 = 0
10h 16 AES lock 13..16 x bit 0..3 = lock 13..16, bit 4..7 = 0
11h 17 AES lock 17..20 x bit 0..3 = lock 17..20, bit 4..7 = 0
12h 18 AES lock 21..24 x bit 0..3 = lock 21..24, bit 4..7 = 0
13h 19 AES lock 25..28 x bit 0..3 = lock 25..28, bit 4..7 = 0
14h 20 AES lock 29..32 x bit 0..3 = lock 29..32, bit 4..7 = 0
15h 21 AES sync 1..4 x bit 0..3 = sync 1..4, bit 4..7 = 0
16h 22 AES sync 5..8 x bit 0..3 = sync 5..8, bit 4..7 = 0
17h 23 AES sync 9..12 x bit 0..3 = sync 9..12, bit 4..7 = 0
18h 24 AES sync 13..16 x bit 0..3 = sync 13..16, bit 4..7 = 0
19h 25 AES sync 17..20 x bit 0..3 = sync 17..20, bit 4..7 = 0
1Ah 26 AES sync 21..24 x bit 0..3 = sync 21..24, bit 4..7 = 0
1Bh 27 AES sync 25..28 x bit 0..3 = sync 25..28, bit 4..7 = 0
1Ch 28 AES sync 29..32 x bit 0..3 = sync 29..32, bit 4..7 = 0
1Dh 29 AES audio 1..4 x bit 0..3 = audio 1..4, bit 4..7 = 0
1Eh 30 AES audio 5..8 x bit 0..3 = audio 5..8, bit 4..7 = 0
1Fh 31 AES audio 9..12 x bit 0..3 = audio 9..12, bit 4..7 = 0
20h 32 AES audio 13..16 x bit 0..3 = audio 13..16, bit 4..7 = 0
21h 33 AES audio 17..20 x bit 0..3 = audio 17..20, bit 4..7 = 0
22h 34 AES audio 21..24 x bit 0..3 = audio 21..24, bit 4..7 = 0
23h 35 AES audio 25..28 x bit 0..3 = audio 25..28, bit 4..7 = 0
24h 36 AES audio 29..32 x bit 0..3 = audio 29..32, bit 4..7 = 0
25h 37 set device id x (request displays in header)
