RCF TT 08-A MKII [14/16] Specifications

ITALIANO

SPECIFICATIONS

TT08-A II TT10-A TT20-CXA

ACOUSTICAL

Operating frequency range 65 - 20.000 Hz 60 - 20.000 Hz 60 - 20.000 Hz

Max SPL 128 dB 130 dB 131 dB

Coverage 90° x 70° 90° x 70° 90° x 70°

Crossover point 900 Hz 900 Hz 900 Hz

TRANSDUCERS

Low frequency 8” neo, 2.5” v.c. 10” neo, 2.5” v.c. 2 x 8’’ neo, 2.5’’ v.c

High frequency 1” neo, 1.75” v.c. 1” neo, 1.75” v.c. 1.4” neo, 3.0” v.c.

AMPLIFIER

Total power 2000 Watt 2000 Watt 2000 Watt

Low section 1400 Watt 1400 Watt 1400 Watt

High section 600 Watt 600 Watt 600 Watt

CONNECTIONS

Signal Input/Output XLR, RDNet Ethercon

Power Input/Output Powercon IN/OUT

CONTROLS Bypass, Linear / High Pass, Volume

COOLING Convection

PROTECTIONS Thermal, HF

MECHANICAL

Cabinet Baltic Birch Plywood

Handles 1 top

Hardware 3 x M10 top and bottom; 2 x PIN D.10 and M10 side -

Size (w, h, d) 270 x 450 x 278 306 x 490 x 299 445 x 318 x 450

Weight 11 Kg 12.5 Kg 15.5 Kg
