KMT12/KMT18

REV. A18

img. A

A1) Connected Devices Indicator shows the number of detected connected devices. N.B.: At startup, the indicator

will show 0 devices, even if one or more units are connected. To detect all connected devices, click the “Connect”

button (A2).

A2) Connect Button detects connected devices.

A3) Demo Button activates the demo mode of K-Framework. In this mode, all devices that can be mangaed with the

K-Framework software appear in the Connected Devices Menu on the left, so that the user can navigate through all

the dedicated tabs and have a glimpse of the different functions available for each unit.

A4) K-array Device List displays all devices presently connected to the network. N.B.: at startup the List will be

empty, even if one or more units are connected. To detect all connected devices, just click the “Connect”

button (A2).

A5) Account Button opens the Account Settings Window where users can insert User Name and Password to access

the K-Array Community and the shared preset database.

A6) Zoom Buttons zoom in (+) and out (-) of the window view.

Click the Connect button to detect all presently connected devices.

All detected devices will appear in the K-Array Device list, as shown in Image B (below):

At startup K-Framework will show the following window:
